Dome Antenna (75 Ohm)

SKU: 304419

4g-dome-antenna-75-ohm-304419
Check Mark Icon

3 Year Warranty

from Purchase

Design Icon

Tailored Solutions

Custom System Design

Location Icon

Assembled & Shipped

from a U.S. Facility


Product Description

Dome Antenna (75 Ohm)

The WilsonPro Dome Ceiling Antenna for indoor residential installation provides wide band coverage cell signal amplifiers on the 698-960/1710-2700 MHz frequency bands. Omnidirectional signal pattern receives and transmits 360 degrees and provides up to 5.1 dB gain. Low profile white dome fits with virtually any decor. Works with 75 Ohm devices on all U.S. and Canada cell carriers. Features built in ground plane and includes mounting hardware. F-Female connector. Dimensions 7.3 inches diameter (185 mm) by 3.3 inches high (85 mm).

Specs

Model304419
ConnectorsF-Female
Dimensions6.38 x 6.38 x 6.38 in
Frequency1710-1880 MHz 4.02110-2170 MHz 4.01850-1990 MHz 4.0824-894 MHz 2.0700-800 MHz 2.0880-960 MHz 2.0
Impedance75 Ohm
Max Gain5.1 dB
Weight0.63
